ذخیره ساز تحت شبکه کیونپ TES-1885U-D1521-8GR
TES1885UD15218GR
QNAP TES-1885U D1521 8GR EU 18-Bay Network Storage
گارانتی پانا
کد کالا:
Lion-Product-777331
ناموجود
| CPU | Intel® Xeon® Processor D-1521, 4-core 2.4 GHz |
| System Memory | Total DIMM slots: 4 Maximum memory: DDR4 128 GB ( 32 GB RDIMM x 4 ) Memory modules pre-installed: TES-1885U-D1521-8GR: 8 GB ECC RAM ( 8 GB RDIMM x 1 ) Note: TES-1885U requires at least 32GB RAM for running QES operating system. |
| Flash Memory | 4 GB DOM |
| Drive Bay | Front: 2.5" / 3.5" x 12 Rear: 2.5" SSD slot x 6 |
| Drive Compatibility | Front: SAS 12Gb/s, SAS 6Gb/s, SATA 6Gb/s HDD and SSD Rear: SATA 6Gb/s SSD |
| USB Port | 2 x USB 3.0 port (rear) For QTS OS: The USB slots support pen drives and other USB-ready devices such as printers, UPS, etc. For QES OS: The USB slots are only reserved for development and debugging. |
| Gigabit Ethernet Port | 2 x SFP+ 10GbE ports, 4 x Gigabit ports |
| LED Indicators | 10 GbE, Status, LAN, Storage expansion port status |
| Buttons | System: Power button and reset button |
| Form Factor | 2U, Rackmount |
| Dimensions (H x W x D) | 88 x 442.5 x 530.5 mm 3.46 x 17.42 x 20.89 inch |
| Weight | Net weight (NAS only): 15.34 kg (33.82 lbs) Gross weight (with packing and accessories): 21.25 kg (46.85 lbs) |
| Operating Temperature & Relative Humidity | 0-40˚C, 5~95% non-condensing, wet bulb: 27˚C. |
| Power Consumption (W) | In Operation: 229.53W |
| Power Supply Unit | Redundant power: Input 90~264VAC; 450W x 2 |
| PCIe Slot | Number: 4 Slot 1: PCIe Gen.3 x8Slot 2: PCIe Gen.2 x4 Slot 3: PCIe Gen.3 x4 Slot 4: PCIe Gen.3 x4 or PCIe Gen.3 x8 Note: Slot 4 provides the width of PCIe Gen.3 x8 when slot 3 is not in use. Slot 4 then provides the width of PCIe Gen.3 x4 only when an expansion board is installed in slot 3. |
| Fan | 4 x 6 cm smart cooling fan |
هارد اینترنال
سازنده
QNAP
فرم ظاهری
3.5 اینچ
رابط
SATA III
ظرفیت
6 ترابایت
حافظه کش
64 مگابایت
سرعت چرخش
5400 دور در دقیقه
