هارد تحت شبکه کیونپ TVS-463 4G 4-Bay Network Storage
TVS463 4G 4Bay Network Storage
گارانتی (پانا)
-
10GbE-ready, highly-efficient storage solution for HD video editing and sharing
-
Enhanced data security with a high-performance hardware-accelerated encryption engine with AES 256-bit full NAS volume encryption and anti-virus
-
Use the TVS-463 as a PC with exclusive QvPC Technology and 4K display support
-
Run multiple Windows/Linux/Android-based virtual machines with the Virtualization Station
-
Manage, share, and back up business data with Real-time Remote Replication (RTRR)
-
NAS and iSCSI-SAN(IP-SAN) unified storage solution for server virtualization
-
Supports VMware®, Citrix®, and Microsoft® Hyper-V and advanced virtualization features
-
Transcode Full HD videos on-the-fly or offline with QNAP’s unique transcoding technology and hardware transcoding engine*
-
Expand the total raw storage capacity up to 160TB with the economical UX-800P QNAP expansion enclosures
CPU | AMD® 2.4GHz quad-core x86 processor with Radeon™ graphics |
---|---|
DRAM | TVS-463-4G: 4GB DDR3L-1600 x 1 TVS-463-8G: 8GB DDR3L-1600 x 1 Total memory slots: 2 Memory expandable up to: 16 GB (8GB x2) NOTE: For the information of RAM module installation and compatible NAS models, please refer to the QNAP RAM Module Installation Guide. |
Flash Memory | 512MB DOM |
Hard Disk Drive | 4 x 3.5”or 2.5”SATA 6Gb/s, SATA 3Gb/s hard drive or SSD NOTE: 1. The system is shipped without HDD. 2. For the HDD compatibility list, please visit https://www.qnap.com/compatibility/ |
Hard Drive Tray | 4 x Hot-swappable tray |
LAN Port | 2 x Gigabit RJ-45 Ethernet port (Onboard:2, expandable to max 4 ports via PCI-E NIC) |
PCIe Slot | 1 (PCIe Gen2 x 4) |
LCD Panel | Mono-LCD display with backlight, Enter and Select buttons for configuration |
LED Indicators | Power, Status, LAN, USB, HDD 1-4 |
USB | 5 x USB 3.0 port (Front: 1, Rear: 4) Support USB printer, pen drive, and USB UPS etc. |
HDMI | 2 (Mirrored Display), 1.4a Note: 4K video playback and transcoding are not supported |
Buttons | Power/Status, USB One-Touch-Backup, reset |
Alarm Buzzer | System warning |
IR Receiver | QNAP RM-IR002 and MCE-compatible remotes |
Form Factor | Tower |
Dimensions | 177(H)x 180(W) x 235(D) mm 6.97(H) x 7.09(W) x 9.25(D) inch |
Weight | Net: 4.56 kg (10.05lbs) Gross: 5.70 kg (12.57lbs) |
Power Consumption(W) | S3 sleep: 2.26W HDD standby: 34.77W In operation:50.38W (with 4 x 2TB HDDs installed) |
Sound Level* | Sound pressure (LpAm): 18.2 dB(A) |
Temperature | 0-40˚C |
Humidity | 5~95% RH non-condensing, wet bulb: 27˚C |
Power Supply | ATX 250W, 110-240V AC, 50-60Hz, 5A |
Secure Design | Kensington security slot for theft prevention |
Fan | 1 x quiet cooling fan (12 cm, 12V DC) |
* Testing Environment:
Refer to ISO 7779 ; Maximum HDD loaded ; Bystander Position ; Average data from 1 meter in front of operating NAS
