مودم روترایسوس DSL-N14U B1
DSLN14U B1
ASUS DSL-N14U B1 Wireless ADSL2 Modem Router
کد کالا:
Lion-Product-9546
ناموجود
- Dual-purpose 300 Mbps wireless ADSL Modem Router
- USB port for network print server, file sharing, Download Master and media server
- ASUSWRT Dashboard for easy 30-second setup and advanced network control via an intuitive graphical interface
- PPTP server for secure VPN data transmission
- ASUS AiCloud allows you to access, sync, share and stream data from your home network to any internet-connected PC, Android or iOS device
- Network Standard IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IPv4, IPv6
- Product Segment N300 complete networking : 300 Mbps
- Wi-Fi Data Rate 802.11b : 1, 2, 5.5, 11 Mbps
802.11g : 6,9,12,18,24,36,48,54 Mbps
802.11n : up to 300 Mbps - xDSL Data Rate ANSI T1.413i2
ITU G.922.1(G.dmt).ITU G.922.2 (G.lite)
ITU G.922.3 ADSL2(G.dmt.bis)
ITU G.922.4(G.lite.bis)
ITU G.922.5(G.dmt.bisplus)
ADSL/ADSL2/ADSL2+ multimode AnnexA,AnnexB compliant
ADSL 2/2+ 24Mbps downstream
Support Annex A/B/I/J/L/M - Antenna Fixed 2 dBi antenna x 2
- LED Indicator Power, ADSL, Internet, WLAN, LAN x 4, USB x 1
- Button WPS Button, Reset Button, Power Button, Wireless on/off Button
- Ports 1 x RJ11 for ADSL
4 x RJ45 10/100 BaseT for LAN - USB Ports USB 2.0 x 1
- USB Applications Printer Server
FTP Server
Download Master - Operating Frequency 2.4GHz
- Router Special Features AiCloud, Printer server, Download Master, AiDisK, Multiple SSIDs, Parental Control
- Operation Channel 13 Europe (ETSI)
- Memory 64MB DDR / 16MB Flash
- Security 64-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , Radius with 802.1x, WPS support
- Firewall & Access Control NAT and SPI (Stateful Packet Inspection) Firewall
- enable/disable WAN ping
- allow access from WAN
- log of accepted and dropped
Filtering:
- Single Port and Port Range
- URL based
- MAC Address
- DoS protection - Management Web-based GUI configuration
Firmware upgraded, configuration data uploaded and downloaded via Web-based GUI
Auto VPI/VCI detection
Configuration backup and restore
Diagnostics
Log & Trace function - Utilities ADSL Setting Wizards
Device Discovery
Firmware Restoration
Printer Setup Utility - VPN Support IPSec Pass-Through
PPTP Pass-Through
L2TP Pass-Through
PPTP server - Power Adapter AC Input : 100 ~240 V(50~60HZ)
DC Output : 12 V/1 A - Certificates CE
- Dimensions 123 x 190 x 35 ~ cm (WxDxH)
- Weight 314 g (Device Only)
- OS Support Windows® 10
Windows® 8.1
Windows® 8
Windows® 7
Windows® Vista
Windows® XP
Mac OS X or higher
Linux - Package Content DSL-N14U Wireless-N300 ADSL Modem Router
Power Adapter
Quick Start Guide
Support CD (user manual, Utilities)
RJ45 cable, RJ11 cable
Splitter (varies with regions)
مودم
تعداد آنتن
2 عدد
کلید
WPS Button, Reset Button, Power Button, Wireless on/off Button
فرکانس عملکرد
2.4 گیگاهرتز
درگاه USB
دارد
پورت شبکه
1 x RJ11 for ADSL 4 x RJ45 10/100 BaseT for LAN
حافظه
64MB DDR - 16MB Flash
کانال کاری
13 Europe (ETSI)
ارتباط بی سیم
دارد
